美標卸扣

*不能超過工作負荷使用。

 美國CHAVEZ查爾斯美標卸扣大多都是按照美國CROSBY標準尺寸生產的，生產工藝大多為模鍛。美標卸扣相比較比我們國標卸扣，船用卸扣和日式卸扣體積更小，重量更輕，安全系數更高。 工作環境要求零下40度和120度之間，不適于強堿強鹽的環境長期使用。 廣泛用于機械、冶金、

電力、鐵路、水利、港口、礦山、建筑、碼頭、造紙、化工等行業。G-209系列規格有：3/16、1/4、5/16、3/8、7/16、1/2、5/8、3/4、7/8、

1、1-1/8、1-1/4、1-3/8、1-1/2、1-3/4、2、2-1/2。

American Standard shackle (also known as American shackle, high-strength shackle) body is made of 45 steel and cross pin

40Cr by die forging. Products include 6 Series: g-209, g-2130, g-210, g-2150, g-213, g-215. 0.5T 1t 1.5T 2T 3.25t 4.75t 6.5T

8.5t 9.5T 12t 13.5T 17T 25t 35t 55T 85t 120t 150t 200t, more than 20 specifications in total. American Standard shackles

(also known as American shackles and high-strength shackles) are smaller, lighter and safer than our national standard

shackles。

The working environment requires between minus 40 degrees and 120 degrees, which is not suitable for long-term use in strong

alkali and salt environment。

It is widely used in machinery, metallurgy, electric power, railway, water conservancy, port, mine, construction, wharf,

papermaking, chemical industry and other industries。

The test load is 2 times of the rated working load, and the minimum breaking load is 4 times of the rated working load。

Carry out strict sampling and breaking test for each batch of products。

Conduct magnetic particle inspection。

Surface treatment: electro galvanizing, hot galvanizing and painting。
